Re: Team 1202 Build Diary

Post by Spaceman » Thu Sep 13, 2018 6:54 am

So the pan for AWS 56 is to turn up with 4 new bots:

Robototron Mk 5: Tracked lifter

Crabulon: Shufflebot. Not sure I will get as far as a active weapon on this one at the moment.

OAF 3: Critical Fail: A D&D inspired take on the hamsterball concept

R.E.X: Tracked Clampbot.

At the moment all 4 are in the design phase.

Going to save my spinner aspirations for the next AWS at least. The aim for this AWS is for me to finally get 3D printed bots to a AWS.

I shall post some pics when I get the chance
Team 1202

Robototron (Flipper)
Crabulon (Walker)

User avatar
Spaceman
Posts: 170
Joined: Wed May 14, 2014 3:16 pm
Location: Oxfordshire

Re: Team 1202 Build Diary

Post by Spaceman » Wed Sep 19, 2018 1:41 pm

Been having lots of fun printing ABS...

Not 100% there but getting close to printing some pretty good looking parts out of ABS. hopefully means I will have some assembled bots soon.

The PLA test version of Crabulon weighed in at 160g with 20% print. Still lots of weight to add armor, weapons etc but I have redesigned it to use less material for the final print. Id ideally like it to be under the wheeled ant limit prior to any additions.

I still have hopes of all 4 bots making it to AWS 56 at the moment.
Team 1202

Robototron (Flipper)
Crabulon (Walker)

User avatar
Spaceman
Posts: 170
Joined: Wed May 14, 2014 3:16 pm
Location: Oxfordshire

Re: Team 1202 Build Diary

Post by Spaceman » Sun Oct 14, 2018 3:52 pm

So made it to AWS 56 with 3 robots:

Crabulon: Shufflebot walker

Robototron MK 5: 2WD wedgebot that was frankensteiend from Mecano and 3d printed parts.

Afterthought: a test chassis we put in last min.

Also has Shaun along as a team mate in order to entice into the hobby.

we only one one fight via the other robot being unable to continue. so no real wins. Shuan did a good job with driving the two wheeled bots despite them being horrible to control.

despite loosing every match, Crabulon did a great job, Despite loosing 4 legs in a altercation with horizontal spinner of doom we managed to cobble it together to come back.


so for next time I want to focus on making a solid wheeled robot, optimise Crabulon and add weapons!
Team 1202

Robototron (Flipper)
Crabulon (Walker)

Zanbots
Posts: 24
Joined: Sat Feb 03, 2018 8:01 pm

Re: Team 1202 Build Diary

Post by Zanbots » Sun Oct 14, 2018 9:03 pm

Well done with the bots. I really like your shuffle drive. Well deserved sportsmanship award re assembling the bot after getting smashed apart.
Jeremy Hall
Ants; 24601
Oh, Baby!
B-Bot
Valjean

User avatar
Spaceman
Posts: 170
Joined: Wed May 14, 2014 3:16 pm
Location: Oxfordshire

Re: Team 1202 Build Diary

Post by Spaceman » Mon Oct 15, 2018 6:53 am

Zanbots wrote:
Sun Oct 14, 2018 9:03 pm
Well done with the bots. I really like your shuffle drive. Well deserved sportsmanship award re assembling the bot after getting smashed apart.
Very kind of you to say.

I spent a good Sunday afternoon starting design on the next Crabulon. I shall post some screen shots soon.
Team 1202

Robototron (Flipper)
Crabulon (Walker)

Zarak
Posts: 1
Joined: Sun Jul 01, 2018 7:15 pm

Re: Team 1202 Build Diary

Post by Zarak » Tue Oct 16, 2018 4:20 pm

You thought of building a spinner robot.... hurricanado

User avatar
Spaceman
Posts: 170
Joined: Wed May 14, 2014 3:16 pm
Location: Oxfordshire

Re: Team 1202 Build Diary

Post by Spaceman » Wed Oct 17, 2018 6:48 am

Zarak wrote:
Tue Oct 16, 2018 4:20 pm
You thought of building a spinner robot.... hurricanado
This would be the right thing to do. It would have to be a full body spinner.

Fun trivia: the original Robototron corpse (because that all it is now) is now signed by Evil scarecrow.

Also: Evil scarecrow would be a great name for a robot.
Team 1202

Robototron (Flipper)
Crabulon (Walker)

haz
Posts: 1840
Joined: Thu Apr 15, 2010 11:20 am
Location: Underwater Lair
Contact:

Re: Team 1202 Build Diary

Post by haz » Wed Oct 17, 2018 7:02 am

Bringing back bloodstock memories :)

Loving the robots too!

User avatar
Spaceman
Posts: 170
Joined: Wed May 14, 2014 3:16 pm
Location: Oxfordshire

Re: Team 1202 Build Diary

Post by Spaceman » Wed Oct 17, 2018 7:39 am

haz wrote:
Wed Oct 17, 2018 7:02 am
Bringing back bloodstock memories :)

Loving the robots too!
2014 Evil Scarecrow opening slot per chance?
Team 1202

Robototron (Flipper)
Crabulon (Walker)

User avatar
Spaceman
Posts: 170
Joined: Wed May 14, 2014 3:16 pm
Location: Oxfordshire

Re: Team 1202 Build Diary

Post by Spaceman » Mon Oct 22, 2018 8:25 am

So my next question...

I managed to get printing with ABS but has cause some issues.

Is PLA + worth using and is it standard PLA temps?
